Restaurant Hotel Kitchen Equipment Commercial Hood Type Dishwasher
Rack Conveyor Dishwasher
Conveyor Type Restaurant Dishwasher
- Capacity per hour: 200 racks.
- Long lasting operation as all components including tank,boiler,wash
and rinse arms are made of stainless steel 304.
- All internal components are easy to remove and clean.
- Auto start/stop levers further reduce water and energy consumption.
- Integrated splash hood avoids splash and makes it wasy to switch
direction during installation.
- Various range suitable to both hot and cold main water supply
temperature.
Quick Details
Power Source:Electric App-Controlled:Yes
Private Mold:Yes Type:Freestanding
Control Type:Full-Integrated Style:dishwasher / dishwashing
equipment
Housing Material:Stainless steel Inner Material:Stainless steel
Power (W):44000 Voltage (V):380 Color:Silver
1 Up and down rotary washing and rinsing, all-round coverage of
dishes to ensure the cleaning effect
2 Adopting highly intelligent and precise control technology,
energy consumption is 20-30% less than traditional ones
3 Push-button operation panel
4 Unique laminated door design, both heat preservation and heat
insulation, can effectively reduce noise
5 The whole machine is made of S.S. 304, and all the spare parts
are made of high quality products. High efficiency Italian water
pump to ensure washing power
6 Fully enclosed base plate, insect and rodent proof design
7 Reasonable and compact size to ensure the washing effect while
minimizing the space occupied in the kitchen
8 Large LCD operation panel, simple to operate
9 With energy-saving module (patented technology), using the waste
heat recovery function, saving energy consumption by 14%
10 Equipped with emergency stop switch, convenient for the operator
to stop the operation of the machine in an emergency
Specifications:
| Rated Voltage(V/N/Hz) | 380/3/50 |
| Rated Power(kW) | 5.73 |
| Electric Current(A) | 8.7 |
| Main Heating Power(kW) | 3 |
| Main Wash Pump Power(kW) | 0.73 |
| Rinse Heating Power(kW) | 5 |
| Rinse Pump Power(kW) | 0.15 |
| Water Tank Capacity(L) | 25 |
| Heat Tank Capadity(L) | 10 |
| Power Line Specifications(mm2) | 4 |
| PowerLine Length(m) | 3 |
| Water lnlet(DN | 20 |
| Drainage(DN) | 32 |
| Water Pressure(MPa) | 0.15-0.35 |
| Water MainWash Temperature(°C) | 55-65 |
| Water Rinse Temperature(C) | 82-90 |
| Water Inlet Temperature(C) | 20-60 |
| Enter Water Hardness(Mg/L) | 34~103 |
| Minimum Water Flow(L/H) | 150 |
| Washing Cyle | 60/90/120 |
| Packing Size(mm) | 840*770"1560 |
| Net Weight(kg) | 123 |
| Gros5Weight(kg | 133 |
About Us:
Guangdong Hengze Commercial Kitchen Equipment Co., Ltd.. was
established in 2016 and located in Shunde Foshan, China. It is a
leading enterprise in the commercial dishwasher equipment industry
with strong technical strength and complete production lines.
We are a professional manufacturer specialized in commercial
dishwasher equipment with many years experiences. Now we have 4
main dishwasher products including hood type dishwasher, rack
conveyor dishwasher and Long line conveyor dishwasher,Bubble
Washing Machine . High quality is the most important point for us
to make sure our final customers have perfect satisfied using
experience. By now, we have cooperated with many Hotels, Schools,
Company groups, Hospitals and Restaurants also we have exported our
dishwasher into many countries out of China rely on the advantage
of our competitive price, high quality, fast producing and
delivery.
Hengze has been committed to providing international standard
quality commercial dishwasher products and one-stop solutions for
all partners. We have the most advanced laser cutting machine,
bending machine. From product development to production inspection,
we have a complete set of quality control process. Also we have
obtained CE ISO14001 ISO9001 certification. Selling well in all
cities and provinces around China, the products are also exported
to customers all of the world as the United States, Japan,
Malaysia, Thailand, Singapore, Qatar, India, Africa, Kazakhstan and
Saudi Arabia.
We have an experienced products development team making sure to
provide OEM/ODM service with high-quality. Whether selecting a
current product from our catalog or seeking engineering assistance
for your requirement you can talk to our customer service center
about your sourcing requirements. We must provide you professional
services with nice price, high quality and fast delivery.
