Features:
1 The feet at the bottom of the machine can be adjusted to a
minimum of 155mm and a maximum of 185mm.
2 The height of the machine can be flexibly adjusted according to
the height of the kitchen worktop for ease of use.▪
Low-power/power-saving machines (save electricity)
3 We offer low power models of 5, 7, and 9KW, which save more than
50% electricity in use than other brands of dishwashers with the
same cleaning effect.▪ Heat recovery tank
4 With the new design of reusing the warm water from the large
tank, the low power machines (5~9kw) will save 30~40% energy.▪
5 Touch screen control panel.Neat and concise appearance, sturdy
and durable, responsive and more convenient to use.▪
6 Round see-through window design.
7 You can observe the whole washing process from outside the
dishwasher to confirm whether the washing process is safe and
hygienic.▪ 3 316L heating rods and dispenser built-in.2 heating
rods are installed in the rinse tank for fast heating to increase
the water temperature;
8 heating rod (800W) Installed in the main wash water tank;
built-in distributor.▪ 220V for energy-saving type, 380V for
high-energy type. 9Both 220V and 380V are available for use
(5KW,7KW,9KW,12KW ).▪ Two motors (double pump).Machine built-in
Chinese cleaning motor and Korean original rinsing motor, the
machine works more efficiently.
| Model No | 40E |
| Product Name | Undercounter Dishwasher |
| Length×Width×Height | 570x620x796 |
| Rated voltage | 220V |380V/50Hz/3P |
| Rated Power | 5.9/7.4 |
| Washingheating power | 1/1 |
| Rinsing heating power | 4.5/6 |
| Washing pump power | 0.37 |
| Washing temperature(℃) | 55~65 |
| Rinsing temperature(℃) | 80~90 |
| Water consumption(L/Basket) | 2.3 |
| Capacity(rack/hour) | 50Basket/Hour |
| Installation requirements |
| Switch(A) | ≥32 | ≥25(With leakage protection) |
| Drainage pipe diameter | φ40 |
| Inlet pressure(MPa) | 0.15~0.6 |
| Inlet water temperature(℃) | 10~60 |
| Inlet hardness(mg/L) | ≤50 |
About Us:
Guangdong Hengze Commercial Kitchen Equipment Co., Ltd.. was
established in 2016 and located in Shunde Foshan, China. It is a
leading enterprise in the commercial dishwasher equipment industry
with strong technical strength and complete production lines.
We are a professional manufacturer specialized in commercial
dishwasher equipment with many years experiences. Now we have 4
main dishwasher products including hood type dishwasher, rack
conveyor dishwasher and Long line conveyor dishwasher,Bubble
Washing Machine . High quality is the most important point for us
to make sure our final customers have perfect satisfied using
experience. By now, we have cooperated with many Hotels, Schools,
Company groups, Hospitals and Restaurants also we have exported our
dishwasher into many countries out of China rely on the advantage
of our competitive price, high quality, fast producing and
delivery.
Hengze has been committed to providing international standard
quality commercial dishwasher products and one-stop solutions for
all partners. We have the most advanced laser cutting machine,
bending machine. From product development to production inspection,
we have a complete set of quality control process. Also we have
obtained CE ISO14001 ISO9001 certification. Selling well in all
cities and provinces around China, the products are also exported
to customers all of the world as the United States, Japan,
Malaysia, Thailand, Singapore, Qatar, India, Africa, Kazakhstan and
Saudi Arabia.
We have an experienced products development team making sure to
provide OEM/ODM service with high-quality. Whether selecting a
current product from our catalog or seeking engineering assistance
for your requirement you can talk to our customer service center
about your sourcing requirements. We must provide you professional
services with nice price, high quality and fast delivery.
