    Commercial Water Saver Flight Type Dishwasher 380V 50Hz Rated Voltage

    Ask Lasest Price
    Brand Name : HENGZE
    Model Number : HZ-4100
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T, Western Union , MoneyGram
    Supply Ability : 100+unit+15days
    Delivery Time : 15 work days
    • Product Details
    • Company Profile

    Commercial Water Saver Flight Type Dishwasher 380V 50Hz Rated Voltage

    Water Saver Commercial Flight Type Dishwasher

    Quick Details


    Rated voltage(V/N/Hz)380/3/50
    Rated Power(kW)61.56
    ElecricCurrent(A93.5
    Main Heating Power(kV)18
    Main Wash Pump Power(k)1.5
    Rinse Heating Power(kwj30

    Features:

    1 Stable control system, simple mechanical operation panel, with LED temperature display, alarm prompt and fault diagnosis
    2 Inclined track to keep the tableware at the best cleaning angle
    3 When the tableware enters the machine, the infrared sensor starts the washing process
    4 Each cleaning module is equipped with 8 concave anti-blocking spray feeding arms to ensure a larger range of fan-shaped water flow and better cleaning performance;
    5 The wash arm and spray arm adopt a pull-out structure, which is more convenient to disassemble and clean
    6 Double-channel spraying system, better spraying effect, effectively reducing water consumption;
    7 Import and export double gear design, reduce chain wear

    Specifications:


    ModelNoEARD
    Product NameTriple Tanks Commercial Dishwashing Machine With Double Rinse Arms Slagging
    ength×width×Height5100x862+450x2000
    Rated voltage(V/N/Hz)380/3/50
    Rated Power(kW)61.56
    ElecricCurrent(A93.5
    Main Heating Power(kV)18
    Main Wash Pump Power(k)1.5
    Rinse Heating Power(kwj30
    Rinse Pump Power(kW)0.37
    Slag removal power(kw)1.56
    Water Tank volume(l)98
    Capacty of slag removalcylinder(L)80
    Heating PattemnElectrka
    Water Main Wash Temperature(℃)55~65
    Water Rinse Temperature(℃)82~90
    Washing Capacity(Dishes/H)(Pcs)4300~6400
    Water Consumption (L/H)≤600
    Drying Heating Power (kw)9
    Drying Power (kw)0.75
    Drying Temperature 〇C)55~85

    Inatallation and Connerction Requirements

    a) Separate power supply all - pole disconnection and water source switch manual valves must be installed.For cutting off the power and water supply of the machine respectively

    b) The power supply, inlet pipeline, drainage pipeline, steam pipeline and ventilation pipeline connected with the machine must meet the relevant national standards

    c) External piping connected to the machine is installed on site
